10Gbps強度調制速率,單SMA射頻口, 偏壓與驅動二合一. 內置光衰減器, 低驅動電壓.
Features
Ti-diffusion process
Single-drive technology
C- and L-band models
Slim, hermetic package
Bandwidths up to 10 GHz
Operational over a temperature range of 0 °C to 70 °C
43 Ohm design for minimal electrical reflections
Angled interfaces for minimal optical reflections
Integrated optical attenuator available on 10 Gbits/s modulator (2623NA)
Tested to Telcordia Technologies * 468
Benefits
Excellent long-term bias stability
Internal polarizer
Low modulation voltages
Applications
Digital high-speed telecommunications:
— SONET: OC-1 through OC-192
— SDH: STM-16, STM-64
— Undersea communications
Internet data communications
SONET/SDH test equipment
